Every wet crawl space in Wheaton is a slow-motion disaster for the wood structure above it. Our heavy-duty vapor barrier systems stop ground moisture permanently.
Four things our Wheaton customers consistently point to when recommending us.
Heavy puncture-resistant poly barriers stay intact through decades of crawl space activity, inspection visits, and seasonal ground movement.
A barrier with unsealed seams and penetrations stops only a fraction of the moisture it could -- our sealed system approach eliminates every bypass path.
HVAC equipment running in an encapsulated crawl space operates at higher efficiency because humidity does not overload the system's dehumidification capacity.
We inspect floor joists, beams, and support posts as part of every assessment and flag any existing wood damage that requires remediation before encapsulation is installed.
Crawl space encapsulation is the process of sealing a home's crawl space against outside air and ground moisture by installing a continuous vapor barrier on the floor and walls, sealing all vents and penetrations, and managing the internal humidity of the sealed space with a dedicated dehumidifier or conditioned air supply. The result is a semi-conditioned space that behaves like a dry indoor environment rather than an extension of the outside soil -- eliminating the ground moisture evaporation that is the primary driver of crawl space mold and wood rot. In Wheaton, IL, where soil moisture conditions fluctuate significantly with the seasons, encapsulation provides consistent protection year-round that passive venting strategies cannot match.
Seam treatment is what separates a professionally installed system from a DIY job that looks similar from a distance. Every seam in our installations is lapped a minimum of 12 inches and taped with a 4-inch crawl space tape rated for the temperature and humidity cycle of your crawl space. Penetrations for plumbing pipes, support columns, and structural posts are individually wrapped with additional barrier material and taped circumferentially so the junction between the pipe and the barrier is fully sealed. A barrier with unsealed seams can still allow significant moisture vapor migration because vapor follows the path of least resistance -- which is any gap, however small.
HVAC performance in homes with encapsulated crawl spaces improves because the humidity load on the air conditioning system is reduced. In a vented crawl space, humid outside air is drawn under the house, rises through the subfloor into the living space, and must be removed by the air conditioning system. This hidden moisture load causes air conditioners to run longer, increases compressor wear, and reduces the effective cooling capacity of the system. After encapsulation, the crawl space humidity is maintained by a rated standalone dehumidifier that handles only the manageable internal moisture load rather than an endless supply from outside air.
Crawl space dehumidification is the final element of a complete encapsulation system. Even a fully sealed crawl space generates some internal humidity from concrete foundation walls and the residual moisture in the soil, particularly in the first season after installation when the soil is transitioning to a lower equilibrium moisture content. A rated crawl space dehumidifier sized to the cubic footage of the space maintains interior relative humidity below the threshold that supports mold growth. We specify units with gravity drain or condensate pump to eliminate the manual emptying requirement, and we set the humidistat to an appropriate setpoint for Wheaton, IL conditions before completing each project.
Six crawl space services that address every moisture source under your Wheaton home.
20-mil reinforced poly barrier installed across the entire crawl space floor and up foundation walls, sealed at all seams and penetrations for complete moisture control.
Rated standalone crawl space dehumidifiers installed with gravity drain or condensate pump, sized to the cubic footage of your specific crawl space and set to maintain safe humidity levels year-round.
Existing foundation vents are sealed with rigid foam insulation cut to size and adhered with spray foam to eliminate the primary pathway for outside humid air to enter the crawl space.
Post-treatment borate preservative application inhibits future mold and decay fungi development on all treated wood surfaces under conditions of elevated humidity.
Drainage channels are integrated under the vapor barrier perimeter, routing water to a sump pit with a submersible pump sized for your drainage area.
We install weatherstripping and rigid foam panel inserts on all access points sized to provide an airtight fit that maintains the pressure balance of the sealed crawl space.
We enter the crawl space and conduct a systematic inspection of all floor and wall surfaces, document moisture meter readings at multiple locations, photograph all floor joist and beam conditions, and identify every source of water or moisture entry before recommending any course of action.
Standing water drainage infrastructure is also installed in this phase so the crawl space floor is dry and stable before the vapor barrier goes down.
Foundation vents are sealed with rigid foam insulation and spray foam adhesive, and the crawl space access hatch is fitted with an insulating door seal panel.
A rated crawl space dehumidifier is installed, connected to gravity drain or a condensate pump, and set to the target humidity level for your Wheaton, IL climate before we complete the project.
We noticed musty smells from the first floor for years and assumed it was just an old house. After JCB Waterproofing and Construction encapsulated our crawl space, the smell was gone within two weeks and our summer electric bills dropped noticeably. Should have done this years ago.
JCB Waterproofing and Construction did a full encapsulation in one day and left the crawl space cleaner than it was when they arrived. The dehumidifier they installed has not required any maintenance beyond emptying the drip tray.
I got four quotes and JCB Waterproofing and Construction was the only company that gave me a written spec listing the mil thickness of the poly they were installing. That transparency is why I chose them and their work backed it up completely.
Take the first step toward a healthier, drier home. Contact JCB Waterproofing and Construction for a same-day crawl space inspection.
