Foundation cracks are not all equal -- their orientation, width, location, and rate of growth determine whether they represent a minor sealing concern or a structural emergency requiring immediate engineering intervention. Vertical cracks in poured concrete walls most commonly result from concrete shrinkage as the wall cures or from differential settlement as the soil beneath the footing compresses unevenly. These cracks are typically stable after they form and respond well to polyurethane or epoxy injection. Diagonal cracks that radiate from corners of window and door openings also frequently reflect normal settlement but should be monitored for width increase over time.
The repair method matched to horizontal cracks depends on the degree of deflection and the construction type of the wall. For poured concrete walls with deflection below critical thresholds, a carbon fiber strap system bonded to the wall face with structural epoxy provides a tensile reinforcement layer that counteracts the lateral earth pressure. For block walls, carbon fiber straps bonded to a plate assembly anchored into the slab and rim joist provide the same function. In both cases the straps are virtually invisible after installation and do not require interior space to accommodate them.
Epoxy injection and polyurethane injection are the two primary methods for sealing and structurally repairing cracks in poured concrete walls. Epoxy injection produces a bond that is actually stronger than the surrounding concrete, making it the correct choice for cracks where structural re-bonding of the two faces is the goal. The process involves drilling a series of small ports along the crack at intervals calculated to ensure complete penetration, installing surface-mounted injection ports, sealing the visible crack face between ports with epoxy paste, and pumping two-component structural epoxy resin under low pressure until it fully fills the void and appears at adjacent ports. The resin cures within the crack to a solid, high-strength bond that is permanent and fully water-resistant.
Soil settlement beneath footings is an independent cause of foundation cracks that requires evaluation separately from the wall repair itself. When soil compresses or washes out from beneath a footing, that section of the foundation wall loses its support and the wall may develop diagonal cracks as the unsupported section deflects downward. In these cases, crack injection addresses the symptom while leaving the root cause unresolved. Our assessment includes a review of grading, drainage, and visible footing conditions to identify signs that settlement is active. Where settlement is a factor, we coordinate the repair approach to address both the crack and the soil condition that created it, preventing recurrence after the crack is sealed.
Six targeted repair services covering every foundation crack condition in Wheaton, IL homes.
Structural epoxy injection bonds the two faces of a poured concrete crack together with a cured material that exceeds the tensile strength of the surrounding concrete, producing a truly permanent structural repair.
Expanding polyurethane resin fills irregular crack voids completely, including geometry that epoxy cannot fully penetrate, and cures to a flexible seal that tolerates minor seasonal wall movement without reopening.
Carbon fiber straps bonded to the interior face of a bowing or horizontally cracked wall provide a permanent tensile reinforcement layer that counteracts lateral earth pressure and stops further wall deflection in its current position.
Wall anchors can be tightened over time as the soil condition allows, potentially restoring some of the original wall plumb position without excavation or more invasive structural work.
We repair stair-step cracks by tuck-pointing the affected mortar joints with a compatible mortar mix matched to the existing wall, reinforcing corner crack locations, and applying a crystalline waterproofer to the repaired area to prevent water intrusion at the newly bonded joints.
We seal the floor-wall joint with a combination of hydraulic cement at active leak points and a flexible polyurethane sealant bead over the sealed joint to accommodate minor movement without allowing the seal to crack again.
Crack mapping, moisture readings, and wall plumb measurements are documented in a written report that accompanies your quote.
Written scope defines every material, method, and warranty term before you approve any work so there are no surprises on the invoice.
Carbon fiber installations include verification of bond strength and strap spacing against the engineered design before the job is signed off.
A written warranty is issued on project completion, covering the repair against reoccurrence under normal conditions for the warranty period stated in your contract.
